5A06 Decorative aluminum strip
5A06 aluminium bar is 5-series Al-Mg anti-rust aluminium. It has high magnesium alloy, good corrosion resistance, good weldability, medium strength.
5A06 is a high magnesium alloy with good strength, corrosion resistance and machinability in non-heat-treated alloys. The anodized surface is beautiful. Arc welding performance is good. The main alloying element in 5A06 alloy is magnesium, which has good corrosion resistance and weldability, as well as medium strength.
It is mainly used for low load parts that require high plasticity and good weldability and work in liquid or gas media, such as oil tank, gasoline or lubricating oil pipe, various liquid containers and other small load parts made by deep drawing: wire used for rivets.
| Alloy | Si | Fe | Cu | Mn | Mg | Cr | Zn | Ti | Al |
| 1050 | 0.25 | 0.4 | 0.05 | 0.05 | 0.05 | — | 0.05 | 0.03 | 99.5 |
| 1070 | 0.2 | 0.25 | 0.04 | 0.03 | 0.03 | — | 0.04 | 0.03 | 99.7 |
| 1100 | 0.95 Si + Fe | 0.05-0.20 | 0.05 | — | — | 0.1 | — | 99 | |
| 2024 | 0.5 | 0.5 | 3.8-4.9 | 0.30-0.9 | 1.2-1.8 | 0.1 | 0.25 | 0.15 | Rem. |
| 3003 | 0.6 | 0.7 | 0.05-0.20 | 1.0-1.5 | — | — | 0.1 | — | Rem. |
| 3004 | 0.3 | 0.7 | 0.25 | 1.0-1.5 | 0.8-1.3 | — | 0.25 | — | Rem. |
| 3005 | 0.6 | 0.7 | 0.3 | 1.0-1.5 | 0.20-0.6 | 0.1 | 0.25 | 0.1 | Rem. |
| 5005 | 0.3 | 0.7 | 0.2 | 0.2 | 0.50-1.1 | 0.1 | 0.25 | — | Rem. |
| 5052 | 0.25 | 0.4 | 0.1 | 0.1 | 2.2-2.8 | 0.15-0.35 | 0.1 | — | Rem. |
| 5252 | 0.08 | 0.1 | 0.1 | 0.1 | 2.2-2.8 | — | 0.05 | — | Rem. |
| 6061 | 0.40-0.8 | 0.7 | 0.15-0.40 | 0.15 | 0.8-1.2 | 0.04-0.35 | 0.25 | 0.15 | Rem. |
| 7075 | 0.4 | 0.5 | 1.2-2.0 | 0.3 | 2.1-2.9 | 0.18-0.28 | 5.1-6.1 | 0.2 | Rem. |
Excellent Weldability: 5A06 aluminium bar can well meet the requirements of different welding methods. Such as arc welding, gas welding, spot welding, argon arc welding, etc.
Good Corrosion Resistance: 5A06 aluminum alloy is a high magnesium alloy, the main alloy Mg content is very high, has good corrosion resistance.
Mechanical Properties: 5A06 aluminum conditional yield strength σ0.2(MPa)≥160.
Other Features: The anodizing treatment of the 5A06 aluminium sheet has obvious effects, and the formability is good.
